OBERTON 15NXB1200
OBERTON 15NXB1200 15” Neodymium Woofer, 4” voice coil, 1200 W, 97 dB, 8 Ohm
- Condition: New
- Stock: Pre-Order
- Model: 15NXB1200
0.00€
Price Ex Vat
speakers
technology
sound
The 15NXB1200 is neodymium bass loudspeaker designed to deliver high impact bass response, with exceptional high power capacity. It features 29 mm high split sandwich voice coil, aluminium die cast frame with triple demodulating rings and vented neodymium magnet structure.
The massive heatsink improve the cooling of the magnet structure, which reduce power compression. This results in an incredible high efficient transducer for subwoofer applications, with the ability to handle high excursion with ultra low distortion and reduced thermal power compression. It is suitable for tuned reflex or horn loaded enclosures for high level subwoofer applications.
| Speaker Diameter | |
| LF Nominal Diameter | 15" / 388 mm |
| Nominal Impedance | |
| LF Nominal Impedance | 8 Ohms |
| Minimum Impedance | |
| LF Minimum Impedance | 6.55 Ohms |
| Power Capacity | |
| LF Power Capacity AES | 1200 W |
| Program Power | |
| LF Program Power | 2400 W |
| Sensitivity | |
| LF Sensitivity | (50 -1000 Hz) 97 dB/W/m |
| Frequency Range | |
| LF Frequency Range | 38 - 1000 Hz |
| Voice Coil Diameter | |
| LF Voice Coil Diameter | 100 mm (4.5 in.) |
| Voice Coil Material | |
| LF Voice Coil Material | Copper |
| Voice Coil Former | |
| LF Voice Coil Former | Glassfiber |
| V.C. Winding Depth | |
| LF V.C. Winding Depth | 29 mm |
| Magnet Gap Depth | |
| LF Magnet Gap Depth | 10 mm |
| Cone Material | |
| LF Cone Material | Paper with carbone fibers |
| Basket Material | |
| LF Basket | Die cast aluminium |
| Magnet Material | |
| LF Magnet Material | Neodymium |
| Flux Density | |
| LF Flux Density | 1.27 T |
